Dell OptiPlex 960 SFF Intel Q45 Motherboard 0G261D LGA775

• Type: Desktop Dell OptiPlex 960 SFF
• Socket Type: Intel LGA755
• Brand: DELL
• Model: DP/N 0G261D, CN-0G261D-70821-9B9-A032Z-A00
• Chipset: Intel Q45 Express Chipset w/ICH10DO
• Front Side Bus: 1333/1066/800 MHz
• Memory: Slots 4
• Memory Speed: Non-ECC 800 MHz DDR2 SDRAM
• Maximum Memory Supported: 8 GB
• Memory Channel Supported: Dual
• Integrated Graphics Port: Intel Graphics Media Accelerator 4500
• Form Factor: uATX
• Onboard LAN: Integrated Intel® 82567LM Ethernet LAN 10/100/1000
• Onboard Audio: ADI 1984A High Definition Audio Codec
• PCI Express x16: 1 low-profile
• PCI Express x1: 0
• PCI: 1 low-profile
• SATA:
• USB 2.0: 8
• Warranty: 30 day CPI limited warranty
• Item #: 78015

View Manufacturer’s Specifications
